Mercedes-Benz have released the latest information and specifications of the new ML63 AMG. This new Mercedes-Benz ML 63 AMG stands for efficiency and performance, exclusivity and a superlative driving experience.
Returning 23.9 mpg (NEDC combined, 276 g CO2/km), the high-performance SUV boasts a 28 per cent improvement in efficiency over its predecessor. The basis for this better fuel consumption and top-class performance is provided by the AMG 5.5-litre V8 biturbo engine with a maximum power output of 525 hp and maximum torque of 700 Newton metres, representing an increase of 15 hp and 70 Newton metres.
There is the option of the AMG Performance package which boosts the V8 engine’s power output to 557 hp and its maximum torque to 760 Newton metres. The newly developed ACTIVE CURVE SYSTEM for active roll stabilisation, the AMG-specific design and the broad scope of standard equipment and appointments provide for a highly attractive overall package.
Ola Källenius, Chairman of Mercedes-AMG GmbH, notes: “Like its predecessors, the new ML 63 AMG sets new standards in terms of performance, exclusivity and a superlative driving experience – plus the efficiency factor, which is acquiring ever greater emphasis at Mercedes-AMG. As the inventor of the high-performance SUV, we remain true to the philosophy which we introduced in 1999 with the ML 55 AMG and continued in 2005 with the ML 63 AMG.”
The new ML 63 AMG comes with a fascinating technology package: the AMG 5.5-litre V8 biturbo engine features spray-guided direct petrol injection with piezo injectors, ECO start/stop system, an all-aluminium crankcase, four valves per cylinder with camshaft adjustment, air-water charge air cooling and generator management, for example. With a displacement of 5461 cc, the eight-cylinder engine generates a maximum power output of 525 hp and 700 Newton metres of torque. In conjunction with the AMG Performance package these values rise to 557 hp and 760 Newton metres. This difference in power and torque results from an increase in the maximum charge pressure from 1.0 to 1.3 bar. Both variants of the ML 63 AMG enable sports-car performance: acceleration from 0-62 mph is achieved in 4.8 seconds and 4.7 seconds if fitted with the AMG Performance Package, while the top speed stands at 155 mph (electronically limited). With or without AMG Performance package, the NEDC fuel consumption level of 23.9 mpg (276 g CO2/km) remains the same. The AMG Performance package further includes an engine cover in high-quality real carbon, callipers in red painted finish and the AMG Performance steering wheel in nappa leather/DINAMICA.
The key data at a glance:
|ML 63 AMG|
|Bore x stroke||98.0 x 90.5 mm|
|Compression ratio||10.0 : 1|
|Output||525 hp at 5250 rpm
557 hp at 5750/rpm*
|Max torque||700 Nm at 1750-5000 rpm
760 Nm at 2000-5000 rpm*
|Engine weight (dry)||204 kg|
|Fuel consumption, NEDC combined||23.9 mpg|
|CO2 emissions||276 g/km|
|Acceleration 0-62 mph||4.8 s
|Top speed||155 mph**|
* with AMG Performance package; ** electronically limited.
Efficient and variable: AMG SPEEDSHIFT PLUS 7G-TRONIC
Power transmission to all four permanently driven wheels is performed by the AMG SPEEDSHIFT PLUS 7G-TRONIC system. Featuring three driving programmes and an automatic double-declutching function for downshifting, this seven-speed automatic transmission offers a fascinatingly broad scope of variability. In “Controlled Efficiency” mode (C) the ECO start/stop function is active, shutting down the eight-cylinder engine when the vehicle is stationary. “C” also stands for a gentle accelerator and transmission characteristic with comfortable and early gear changes; start-up generally takes place in second gear here. A green “ECO” symbol in the AMG instrument cluster indicates to the driver that the ECO start/stop function is active.
In the Sport (S) and Manual (M) driving programmes the ECO start/stop function is inactive and the engine-transmission combination displays far greater agility. A brief and exactly defined retardation of ignition and injection during upshifting at full load additionally provides for shorter shift times here.
Enhanced efficiency and driving dynamics
As efficiency-enhancing measures, the AMG SPEEDSHIFT PLUS 7G-TRONIC automatic transmission incorporates a new fuel economy converter with centrifugal pendulum, bearings designed for reduced friction loss and a transmission-oil thermal management system. Friction loss-minimised axle gears, electronic steering, an optimised belt drive, demand-responsive control of all ancillary units and pumps and an intelligent lightweight design all help to further reduce fuel consumption. The new ML 63 AMG is 40 kilograms lighter than its predecessor – despite the increase in power and the more comprehensive range of standard equipment.
As on the previous model, Mercedes-AMG deploys a specially designed transfer case for the 4MATIC permanent all-wheel drive which distributes the engine power at a ratio of 40 : 60 to the front and rear axle in the interests of high driving dynamics. Furthermore, the AMG sports suspension with AIRMATIC package, air suspension, independent damper struts, automatic level control and Adaptive Damping System (ADS) features for the first time in combination with the ACTIVE CURVE SYSTEM for active roll stabilisation. This system, which comes as standard, employs active anti-roll bars on the front and rear axles to compensate the body’s roll angles during cornering. In addition to enhanced agility and driving enjoyment, the system also improves driving stability for added safety at higher speeds in particular.
Roll stabilisation, damping and suspension adapt instantaneously to the prevailing driving situation, offering both optimum ride comfort and maximum stability. The driver is able to choose at the push of a button between the three driving modes “Comfort”, “Sport” and “Manual”. The fully load-bearing air suspension system is speed-sensitive, lowering the body when higher speeds apply in order to minimise drag while increasing driving stability.
The AMG-specific elastokinematics at the front axle and the more robustly designed rear axle stabiliser bar are responsible for improved steering precision. The enhanced drive train stands for optimum power transmission and hallmark Mercedes reliability. The 4ETS electronic traction control system which features as standard provides for optimised grip when low friction coefficients apply.
AMG speed-sensitive sports steering, AMG high-performance braking system
Electromechanical AMG speed-sensitive sports steering features vehicle speed-dependent power assistance and helps to save fuel, as the steering assist function only requires energy when the driver actually moves the steering wheel. The ML 63 AMG comes as standard with 5-spoke light-alloy wheels in format 9 x 20, painted titanium grey and with a high-sheen finish, fitted with tyres in size 265/45 R 20. Tyres in size 295/35 R 21 on AMG light-alloy wheels in size 10 x 21 are optionally available. The AMG high-performance braking system provides for the shortest possible braking distances and high fade resistance, featuring ventilated and perforated brake discs all-round in size 390 x 36 (front) and 345 x 26 millimetres (rear).
Specific AMG styling with trim in matt silver chrome
The design of the new MG 63 AMG exudes self-confidence, athleticism and power. The AMG styling dominates the front view: under the radiator grille with louvres in high-gloss paint finish and the large Mercedes star is a large cooling air intake on which the number plate is positioned. Together with the two outer air intakes, the central radiator grille provides for an effective flow of air to the water, engine oil, charge air and transmission oil coolers.
Fitted at the bottom of the AMG front apron is a trim strip in matt silver chrome, which lends the front a wider appearance while harmonising with the surrounds of the daytime driving lights in the side cooling air intakes. The headlamps cut a particularly high-quality and exclusive figure in combination with the optional Intelligent Light System (ILS). The AMG front apron is integrated with the distinctive front fenders, which are 10 millimetres wider on either side in order to accommodate the large AMG light-alloy wheels in elegant fashion. “V8 BITURBO” logos identify the vehicle as the top AMG model in the M-Class. Dynamically profiled AMG side sill panels establish a visual link between the front and rear of the vehicle.
Another eye-catching feature is the AMG rear apron highlighting the black air outlet openings. The outlet openings emphasise the vehicle’s width similarly to the trim strip in matt silver chrome, which cites the design of the front apron and frames the AMG sports exhaust system. In contrast to the other M-Class variants, the ML 63 AMG features two sets of chrome twin tailpipes. Typical of an AMG is the distinctive full eight-cylinder sound.
High-quality, sporty interior
A sporty character and premium quality define the interior of the high-performance SUV from AMG. This is embodied in the electrically adjustable AMG sports seats offering pronounced lateral support as well as the four-spoke AMG Performance steering wheel, which ensures optimum control of the vehicle with perforated leather in the grip area, aluminium shift paddles and a flattened bottom rim. Aluminium trim elements and the piano-lacquer retractable cover in the centre console highlight the interior’s special dynamic and exclusive flair. The standard leather upholstery includes contrasting double topstitching and AMG badges in the backrests of the front seats and the outer rear seats. Dashboard, armrests and door panelling in AMG-specific design are finished in ARTICO man-made leather with double topstitching.
The distinctively designed instrument cluster with colour TFT monitor, AMG welcome logo and AMG main menu is exclusive to the ML 63 AMG.
Other standard equipment includes:
• AMG door sills in stainless steel
• AMG sports pedals in brushed stainless steel with rubber studs
• Audio 20 CD radio with Bluetooth and USB interface
• Tyre pressure monitoring system
• Electric sliding glass roof
• Heated seats for driver and front passenger
Exclusive optional extras are also available from the AMG Performance Studio:
• AMGfloor mats
• AMG light-alloy wheels (10 x 21) in 5-spoke design, painted in titanium grey with a high-sheen finish, fitted with tyres in size 295/35 R 21
• AMG Performance steering wheel in nappa leather/DINAMICA
• AMG Performance package with increase in power of 32 hp and 60 Newton metres more torque, AMG engine cover in high-quality real carbon, AMG Performance steering wheel in nappa leather/DINAMICA, callipers in red painted finish
Tailor-made individuality with designo
The designo range enables ML 63 AMG customers to realise their very own personal style. The designo Exclusive package includes nappa leather upholstery on the AMG sports seats featuring an unusual diamond pattern. The leather upholstery is available in designo marron, designo porcelain and designo black. The scope of features also includes AMG badges in the backrests of the front seats and the outer rear seats as well as velour floor mats with designo metal badges and black designo leather edging. A designo roof lining in DINAMICA black rounds off the designo Exclusive package.
Further optional items include designo trims in black piano lacquer and the designo wood/leather steering wheel in black piano lacquer.
Additional optional items:
• Trailer coupling with electric unlocking
• Becker® MAP PILOT
• Electrically operated EASY PACK tailgate
• Rear Seat Entertainment System
• harman/kardon® Logic 7® surround sound system
• Wood/leather steering wheel in nappa leather
• THERMOTRONIC luxury automatic climate control
• Light package including Intelligent Light System
• Media interface
• Memory package
• COMAND Online multimedia system
• Electrical panoramic sliding glass sunroof
• Aluminium-look running boards with rubber studs
• TV tuner
• Wood trims
Safety of the very highest calibre
In line with the Mercedes-Benz brand philosophy, the new ML 63 AMG represents the embodiment of the Mercedes-Benz holistic safety concept of Real Life Safety, which is derived primarily from what happens in a real accident situation. The extremely robust occupant compartment, together with the front and rear deformation zones, forms an effective basis for the occupant protection system. Up to nine airbags, activated on demand in accordance with the accident type and accident severity, can reduce the loads exerted on the occupants. In addition to active safety systems such as the standard-fit Brake Assist (BAS) or the optional BAS PLUS, which can help to prevent an accident or reduce the severity of an accident, the new M-Class features further enhanced passive-safety measures to help protect pedestrians.
Both active safety and driver-fitness safety are improved by assistance systems that will already be familiar, primarily from the S- and E-Class. The standard equipment package includes the drowsiness detection system ATTENTION ASSIST, the anticipatory safety system PRE-SAFE® and a tyre pressure loss warning system, as well as adaptive brake lights and the ESP® electronic stability programme. Active assistance systems such as Active Lane Keeping Assist and Active Blind Spot Assist are available as additional equipment options.
Visionary: AMG as the inventor of the high-performance SUV
The new ML 63 AMG from Mercedes-AMG represents the third generation of the high-performance sport utility vehicle. The company from Affalterbach was the first to identify the potential of powerful and exclusive off-road vehicles and is recognised as the founder of the high-performance SUV segment. It all began in 1999 with the ML 55 AMG: with a power output of 347 hp, the top-of-the-range M-Class model powered by an AMG 5.5-litre V8 engine achieved a level of performance previously undreamt-of in this class, with acceleration from 0-62 mph in just 6.8 seconds and a top speed of 146 mph. The unusual combination of high-calibre drive, excellent off-road capabilities, outstanding ride comfort, unparalleled safety and a spacious interior, delighted AMG customers throughout the world. Over 11,000 ML 55 AMGs were sold between 1999 and 2003.
The follow-up ML 63 AMG which was presented at the Frankfurt International Motor Show in September 2005 continued the success story that had begun with the ML 55 AMG. With its AMG 6.3-litre V8 engine generating an output of 502 hp and 630 Newton metres of torque, it again set the benchmark in its segment. The performance of the ML 63 AMG was in the sports-car league: the top-of-the-range AMG model accelerated from 0-62 mph in 5.0 seconds and had a top speed of 155 mph (electronically limited). Over 13,000 were sold in total between 2006 and 2011.
In all, AMG’s sales figures for its high-performance SUVs total over 24,000 to date.
The new Mercedes-Benz ML 63 AMG will launch in the UK in Spring 2012.
UK Pricing and specifications are still to be confirmed.
